Revit Family Tutorial - Window with Metal Panel Inserts
Feb 02, 2026
This tutorial explains how to create a Revit window family with embedded metal panel inserts. This allows users to avoid manually modeling the metal insert conditions in the project and instead leverage the power of families.
This is a nested family that can be reused in any of your existing window families. The family is included in the lesson (Revit 2026 version).
Project reference: Scandinave by Quinzhee Architectes
